With HPC KAESER CONTAIN-AIR, you can react quickly to any interruptions – regardless of whether due to a compressor outage, backup required during maintenance and repairs, a temporary bottleneck or an emergency situation.
The HPC KAESER containerised compressed air station includes our DSG 290-2 SFC i-HOC dry-running rotary variable speed screw compressor with integrated compressed air dryer.
Delivering oil-free compressed air with reliable pressure dew points, with maximum free air delivery from 12.33 - 28.00 m³/min at 10 bar.
“Plug and play” compressed air station
Connections to your compressed air system is easy.
Our containerised solutions are all perfectly suited for installation outdoors. All that is needed is to connect the electrical, compressed air and condensate lines and the system is ready to go.
HPC KAESER’s turnkey, containerised compressed air stations can be perfectly matched to your exact requirements, thanks to our SIGMA AIR MANAGER 4.0 master controller.
We provide the ideal rental solution for any application – be it for the automotive sector, oil and gas operations, the pharmaceuticals, foodstuffs or beverages industries or PET bottle production.
Technical specifications:
- Container L x W x H: 5,000 x 1,980 x 3,000 mm
- Weight: Approx. 8,700 kg
- Installed rated power: Approx. 217 kW
- Mains voltage: 400V/3Ph (+/- 5%) (L1,L2,L3 + E)
- Frequency: 50 Hz
- Total current: Approx. 390 A
- Maximum back-up fuse: 400 A
- Short-circuit resistance: 50 kA
- Control cabinet protection rating: IP 54
- Recommended electrical cable cross-section: (CU – multi-core) 2x 4x 120 mm² (max. clampable) or 4x240 mm² (max. clampable)
